| Windows Mirroring via software |
| Installation | Keep PC and box at the same internet,No need installation |
| Support System | Windows 7/8/10 |
| Resolution | 1920*1200, 1920*1080,1366*768,1360*768,1280*800,1280*720 1024*768 |
| Frame Rate | Audio&Video 18~30Frame |
| Delay time | 100~200ms |
| Display mode | Support extend screen |
| TouchBackControl | Support Mouse mode return |
| Connection paths number | 128 |
| The most qty display screen | 4 Screens |
| Meeting Mode | Host mode | The host can touch the list of screens to select the designated PC
screen |
| Participant mode | During the meeting,when non-host transmits the screen, whoever
press the button and who can transmit. |
| Connecting Internet | 1. When box connect to RJ45,PC Wi-Fi or wired connection of Network
2. When box connect to Wi-Fi,PC Wi-Fi or wired connection of
Network - PC Wi-Fi Connecting to box 5G hotpot
|
| Wireless USB Dongle |
| Installation | No installation, no configuration |
| Connection | USB Device |
| Support system | Windows 7/8/10,Apple Mac |
| Resolution | 720P~1080P |
| Frame Rate | Audio&Video 18~30Frame |
| Delay time | 100~200ms |
| Transmit distance | No obstacle 30m |
| Display mode | Support extend screen(Windows 7/8/10) |
| TouchBackControl | Support 10 fingers touch returns(Windows 7/8/10) |
| Support mouse mode return (Mac) |
| Connection number | 1~8(If above8pcs, need additional routers) |
| The most qty display screen | Single screen |
| Wireless Speed | TX 300Mbps |
| Wireless Protocol | IEEE 802.11 a/g/n/ac |
| Channel | 5.8G, Multi channel Selection |
| Authentication Protocols | WPA2-PSK |
| Upgrading method | PC USB Upgrading the dongle |
| Meeting Mode | Host Mode | The host can touch the list of screens to select the designated PC
screen |
| Participant mode | During the meeting,when non-host transmits the screen, whoever
press the button and who can transmit. |
| Phones Wiress Mirroring |
| Dual Wi-Fi | 5GHotspot &2.4G Wi-Fi working at same time,While mirroring, the
phone can go surfing. |
| Scanning Screen | Android devices scan QR Codes and casting |
| Cross Segments | Under the same Network, the screen transmission can between
different network segments |
| iPhone | iOS8 above,AirPlay mirroring,support multi-screens mirroring |
| Android phone | Android 5.0 and above, and download USBdisplay.cn APP can mirroring
videos which can pass-through sound |
| MiraPlay Mode | No need APP for mirroring, support Miracast,AirPlay,USB wireless
mirroring |
| Other Functions |
| Rotating | Support 90° 180°270° photos Rotating |
| Dynamic Password | Support APP mirroring, AirPlay,Windows software mirroring |
| Take notes | Single-point Writing(Accelerating Low Delay)Multi-points
Scaling,Gesture Erasure, support scan QR code and share |
| Audio output | HDMI output |
| RTC | Built-in super capacitor to maintain normal operation 1week if
power down |
| Restart Timely | Support timely restart and keep the whole year work normally
without power down. |
| Other APPs | Customization Welcome, files explores and screen saver |
| Router Mode | Support 2.4G&5.8G AP at the same time for mirroring(optional) |
| Video/Audio |
| Video decoding | Support H.264,H.265,VP8,RV,WMV,AVS,H.263,MPEG4 |
| Decoding solution | 4K |
| Touch System |
| Connector | USB HID | Mouse mode | Support |
| IR touch control | Support | Capacitive touch panel | Support |
|
