FHD video wireless transmitter 4K Wireless Collaboration Device
with HDMI in Wi-Fi 6
Quickshare is BYOD wireless presentation system that enables any employee or visitor to share a conference room or
huddle room projector or panel in just seconds simply by plugging
in their notebook and pressing a button.
No wiring required, greatly reducing installation costs and
improving installation efficiency. Easy and convenient to use,
minimizing work in renovating meeting rooms and living rooms.
Features of Wireless Collaboration System:
1. Multiple Devices to Display . Compatible with windows /Mac/
Android / iOS platforms . It Supports mobile phone m notebooks ,
desktop computers , laptops , tablets and many other devices for
mirroring .
2. HDMI IN
3. Display Mode . Support for extended desktops (win7/win10 )
4. Capabilities for touch
5, Wi-Fi 6 5.8G Hotspot+5.8G SAT
6, BYOM Support Shared camera and micro-phone
7, Support Single screen: 4K pixel to pixel, 4 screens: 1080P pixel
to pixel
8, Support USB-wired mirroring
Wireless Presentation System Advantages:
Support native wireless mirroring protocols like Airplay, Miracast,
Chromecast
Support plug-&-play HDMI/TYPE-C/U disk dongles for wireless
connection
Support windows APP for wireless connection
Support 4/9 split screen view
Support reverse control of laptop from touch screen
Best-in-class data security with high standard encryption
Moderation mode support preview function
Support touch and touch back
| Windows Mirroring via software |
| Installation | Keep PC and box at the same internet,No need installation |
| Support System | Windows 7/8/10 |
| Resolution | 4K pixel to pixel, 1920*1080,1366*768,1360*768,1280*800,1280*720 1024*768 |
| Frame Rate | Audio&Video 18~30Frame |
| |
| Wireless USB Dongle |
| Installation | No installation, no configuration |
| Connection | USB Device |
| Support system | Windows 7/8/10,Apple Mac |
| Resolution | 720P~1080P 4K |
| Frame Rate | Audio&Video 18~30Frame |
| Delay time | 100~180ms |
| Transmit distance | No obstacle 50m |
| Display mode | Support extended screen(Windows 7/8/10) |
| TouchBackControl | Support 10 fingers touch returns(Windows 7/8/10) |
| Support mouse mode return (Mac) |
| Connection number | 1~8(If above 8pcs, need additional routers) |
| The most qty display screen | 4/9 screens |
| Wireless Speed | TX 300Mbps |
| Wireless Protocol | IEEE 802.11 a/g/n/ac |
| Channel | 5.8G, Multi channel Selection |
| Authentication Protocols | WPA2-PSK |
| Upgrading method | PC USB Upgrading the dongle |
| Meeting Mode | Host Mode | The host can touch the list of screens to select the designated PC
screen |
| |
| Phones Wiress Mirroring |
| Dual Wi-Fi | WiFi 6 5.8G Hotspot &5.8G Wi-Fi working at same time,While
mirroring, the phone can go surfing. |
| Scanning Screen | Android devices scan QR Codes and casting |
| Cross Segments | Under the same Network, the screen transmission can between
different network segments |
| iPhone | iOS8 above,AirPlay mirroring,support multi-screens mirroring |
| Android phone | Android 5.0 and above, and download USBdisplay.cn APP can mirroring
videos which can pass-through sound |
| MiraPlay Mode | No need APP for mirroring, support Miracast,AirPlay,USB wireless
mirroring |
| Other Functions |
| Rotating | Support 90° 180°270° photos Rotating |
| Dynamic Password | Support APP mirroring, AirPlay,Windows software mirroring |
| Take notes | Single-point Writing(Accelerating Low Delay)Multi-points
Scaling,Gesture Erasure, support scan QR code and share |
| Audio output | HDMI output |
| RTC | Built-in super capacitor to maintain normal operation 1week if
power down |
| Restart Timely | Support timely restart and keep the whole year work normally
without power down. |
| Other APPs | Customization Welcome, files explores and screen saver |
| Router Mode | Support 5.8G&5.8G AP at the same time for mirroring(optional) |
| Video/Audio |
| Video decoding | Support H.264,H.265,VP8,RV,WMV,AVS,H.263,MPEG4 |
| Decoding solution | 4K |
| Touch System |
| Connector | USB HID | Mouse mode | Support |
| IR touch control | Support | Capacitive touch panel | Support |
| Operation System |
| System version | Android 11 | USB | 3 |
| CPU | ARM Cortex A55 x 4 | HDMI output | 1 |
| DDR | 2G /4G | HDMi in | 1 |
| Flash Memory | 8G/32G | RS232 | 1 |
| Lan | RJ45 | IR Receiver | Support |
| Soft AP | 802.11AC 5.8G | Wi-Fi | 5.8G |
|
Pre-sales service:
1) Our company can arrange professionals to conduct site
installation and debugging in strict accordance with the
requirements of the schemes and the original manual. If there is
any special requirement, it is necessary to make changes of part
installation scheme, we will coordinate with users. Our company can
ensure the consistence of completion time and contracted time. Any
problems caused by natural factors or man-made, we will discuss
with client to find solutions.
2) Our company can train the users based on the manual. The
training include system use, system maintenance and equipment
protection
FAQ
Q: Are you a manufacturer or a trading company ?
A: We're professional manufacturer of Wireless Presentation System, providing one-stop OEM & ODM service to all partners all over the
world.
Q: Are your products conforming to our standards ?
A: Yes, our products can pass the testings as you require, e.g.:
CE, RoHS, ISO9001.
Q: How do you control the quality ?
A: We have perfect QC system (IQC, IPQC, FQC, OQC team),
professional product engineers and continuous improvement system.
Q: What’s the product warranty?
A: We offer 12 months guarantee.
